Frame
Uni-directional carbon mainframe, ZS56 top and bottom head tube, internal cable routing, 6061 Alloy swing arm, Shape.it Link V2 and 12mm x 148mm Boost dropouts, RideWrap frame protection kit fitted as standard
Rear Shock
RockShox Super Deluxe Select RT, DebonAir, Fast Black coating, adjustable rebound, 230 x 62.5mm, custom tuned for Whyte
Fork
RockShox ZEB Select, 180mm travel, 44mm offset, Linear XL, Delta RC damper, Fast Black coating, tapered steerer, 110mm x 15mm Boost, Maxle stealth
Headset
ZS56 upper / lower headset cups for 1 1/8in upper and 1.5in lower with sealed bearings
Stem
Whyte, 35mm Extension, 35mm Bar Bore
Handlebar
Whyte Custom 7050 alloy, 40mm rise, 35mm bar bore, 800mm wide
Bar Tape / Grip
Whyte Enduro lock-on
Brake Levers
SRAM Maven Base hydraulic disc brake, four piston, sintered metal pads, 220/200mm six bolt Centerline rotors
Tyres
Maxxis Assegai WT, TR, 29 x 2.5in 120TPI, EXO+ Sidewall Protection, 3C MaxxGrip, Dual Compound, folding bead (front); Maxxis Minion DHR 2 WT, TR, 27.5 x 2.5in 120TPI, Double Down casing, 3C MaxxTerra, Dual Compound (rear)
Wheels
Whyte eMTB sleeved rims, 30mm internal width, tubeless ready, Alloy, e-bike specific, double sealed cartridge bearings, nine degree micro engagement four pawl, 32 hole, HG freehub Boost spacing, six bolt, 29" front, 27.5" rear
Front Derailleur
N/A
Rear Derailleur
SRAM Eagle 70 T-Type, 12 speed
Shift Levers
SRAM Eagle 90, right, MMX, 12 speed
Chain
SRAM Eagle 70 T-Type Flat-Top, 12 speed
Cassette
SRAM XS 1270, T-Type, 10-52T, 12 speed
Chainset
Whyte 155mm long ISIS crank arms, SRAM direct mount, 36T chainring, T-Type
Bottom Bracket
N/A
Pedals
Fibre reinforced composite platform
Saddle
Whyte Custom
Seatpost
TranzX +RAD adjustable dropper post, 34.9mm, frame size specific drop (size S 150mm drop; size M 170mm drop; sizes L-XL 200mm drop)
