Whyte E-504 V1 Compact Electric Bike - Matt Diesel

Season:2023

Brand:Whyte

Code:WE504

The E-504 electric hardtail offers the same exceptional ride as ourE-505 electric hardtailbut runs on smaller 27.6in wheels with a more compact frame and smaller XS, S and M size options so that smaller riders don’t have to compromise their off-road experience – or their expectations.

Stylishly rugged looks and top quality ‘real off road’ components truly make the E-504 the highly capable Land Rover Defender of e-bikes. Whether you want to ride with friends, stay fit and healthy, explore the countryside, or get the blood pumping pushing your limits, our E-504 electric assist mountain bike is the perfect off-road partner to do it all. With its mix of easy speed and long-range freedom together with the confidence to explore everywhere, it makes any surface from road to forest trails huge fun while taking the worry out of hills and long distances.

Highlights
– Perfect for smaller riders with XS, S, and M compact frame sizes
– A highly capable and confident-inspiring ride
– Light and robust 6061 T-6 aluminum frame
– Powerful and reliable Bosch Performance Line CX 85Nm motor
– Large capacity Bosch PowerTube 500Wh removable battery
– Agile 27.5in (aka ‘640b’) wheels + high volume Maxxis tyres
– Fast-shifting and durable 1x11 SRAM transmission (36T chainring x 11-42T cassette)
– Powerful four-piston hydraulic disc brakes for reliable all-weather braking

Why E-504?
The E-504 takes all that we know about exceptional mountain bike hardtail geometry and adds a powerful and reliable Bosch motor, battery and controls to give you a huge range of everyday use – from trail riding to commuting, or both in one day – together with a confident-inspiring ride feel.

Our E-504 electric mountain bike is designed by the same team as our award-winning conventional mountain bikes and benefits from all their knowledge and riding experience. The same handling genius that our designers use to win national championships is what’ll make you feel totally in control on slippery, bumpy tracks or zooming down a gravel descent in the forest. The upright position and wide bars make just as much sense for cruising back country lanes, short cutting through town or just making the most of the views this bike can take you to.

The powerful, premium Bosch motor will have got you to the top of that hill with effortless ease and the Purion handlebar display will tell you clearly how far you’ve still got to enjoy and explore. Intelligent motor modes give the best possible range from the big 500Wh battery for hours of adventures. Fitting the battery inside the super tough, mountain bike frame keeps it sealed, safe and sleek but it’s easy to remove for charging inside. The frame mounted motor means perfect handling balance and the smoothest ride and just like the internally routed controls it’s fully protected from the weather. Legendary Bosch reliability means you’ll never miss a ride or worry about getting home either.

Features & Equipment
While the E-504 is super easy to ride whatever your biking experience it’s fully ready to back up your bravest moves too. Rolling on agile and capable 27.5in wheels that help keep the riding experience in proportion for smaller riders, we’ve dressed the wide wheel rims with high-volume 27.5x2.6in Maxxis tyres to deliver great grip and comfort off-road. RockShox suspension is the original and best and the SRAM gears are super simple to use whether you need a winch for silly uphills or warp speed down the other side. Four piston disc brakes with oversized rotors guarantee safety whatever the weather too.

Looking for the same ride feel but need a larger L or XL frame size, or a longer reach across a size M? Look at ourE-505 e-hardtailwith its larger 29in wheels. //insert hyperlink//

All our electric assist off road bikes, from the big wheelerE-505to theE-506 SUV//insert link// come with a remote-controlled dropper seat post as standard. This lets you lower the saddle with a switch on the handlebars so you can stop or start with both your feet flat on the floor. It also makes getting on and off the bike easier wherever you are too and even helps when you’re riding by the seat of your pants on trickier trails. That’s why we guarantee if you were wondering why we fit one at first, you’ll soon be wondering how you ride a bike without one.
Technical Information
ColourMatt Diesel with Light Blue & Slate
SizesXS,S,M
Frame6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing for Dropper Post
and 12mm X 148mm Boost Dropouts
ForkRockShox 35 Gold RL 27.5”, 120mm Travel, 37mm Offset, DebonAir, Fast Black Coating, Adjustable Compression and Rebound,
Tapered Steerer, 110mm x 15mm Boost, Maxle Lite
HeadsetFSA No. 57B Orbit ZS, 1 1/2” Lower and 1 1/8” Upper Caged Bearings
Rear HubAlloy, e-bike specific, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Thru Axle, 32 Hole
Front HubAlloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Thru Axle, 31mm Torque Caps, 32 Hole
SpokesDT Swiss Champion 2.0mm, Black Stainless, Brass Nipples
RimsWTB ST i30 TCS 2.0 System, Pinned Joint, Tubeless Ready, 32 Hole
TyresMaxxis Forekaster TR 27.5” x 2.6” 60TPI, EXO Sidewall Protection
Shift LeversSRAM GX, 11 Speed
Rear DerailleurSRAM GX, 11 Speed
CassetteSRAM PG-1130, 11-42, 11 Speed
ChainKMC NPBK Sport, 11 Speed
CranksetWhyte, Steel narrow/wide, 165mm, Direct Mount 36T for Bosch Performance Line CX, Black
Bottom BracketN/A
SeatpostWhyte drop.it, 30.9, XS 100mm, S 125mm, M 150mm Travel, Paddle Remote Lever
SaddleWhyte Custom, Triple Panel Design
HandlebarWhyte 6061 Alloy, XS and S 15mm Rise, 31.8mm, 760mm, M 30mm Rise, 31.8mm, 780mm Wide
StemWhyte Alloy 6061, 35mm Extension
Grips

Whyte Lock-on V Grip
Front Brakes

Tektro Orion, 4-Piston with Sintered Metal Pads, 200mm Disc, Post Mount
Rear BrakesTektro Orion, 4-Piston with Sintered Metal Pads, 200mm Disc, Post Mount, Internal Routing
PedalsNone
Sizing Information
GEOMETRY
SIZEXSSM
HEAD TUBE ANGLE (adjustable to)6464.564.5
SEAT TUBE ANGLE74.574.574.5
TOP TUBE HORIZONTAL569590620
BB HEIGHT ABOVE GROUND (adjustable to)305305305
STAND OVER HEIGHT712728758
WHEEL BASE114611631193
CHAIN STAY LENGTH440440440
SEAT POST DIAMETER30.930.930.9
HEAD TUBE LENGTH107115115
SEAT TUBE LENGTH381406444
