The Alpine Trail E1 is a powerful enduro eMTB featuring a Series 4 aluminum frame, 800Wh battery, and Bosch Gen 5 CX motor. It offers 170mm front and 160mm rear travel, adjustable geometry, and a mixed wheel setup for technical terrain.
The Alpine Trail E1 is a powerful enduro eMTB featuring a Series 4 aluminum frame, 800Wh battery, and Bosch Gen 5 CX motor. It offers 170mm front and 160mm rear travel, adjustable geometry, and a mixed wheel setup for technical terrain.
Marin

Marin Alpine Trail E1 Full Suspension E.Mountain Bike - Gloss Black/ Purple

£4,499.00
Size Guide
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

Marin Alpine Trail E1 Full Suspension E.Mountain Bike - Gloss Black/ Purple

Season:2026

Brand:Marin

Code:7390610PURFADE

The Alpine Trail E1 is a powerful enduro eMTB designed for riders who challenge themselves with the steepest, most technical terrain.

This bike features a lightweight Series 4 aluminum frame, a ride-all-day 800Wh removable battery, and a 2in color Kiox top tube display. Experience the climbing power of Bosch's 120Nm, 600 per cent assist Gen 5 CX motor. The bike offers adjustable geometry, allowing you to swap the upper headset cup for ±0.75-degrees of adjustment and use chainstay flip chips to adjust bottom bracket height and chainstay length. The MultiTrac 2 LT suspension system provides 160mm of travel at the rear, paired with 170mm of travel up front from the X-Fusion Vengeance HLR fork and H3A HLR shock.

Features:

  • Shimano CUES LINKGLIDE 10-speed drivetrain optimized for eMTB motor torque
  • TRP DHR EVO Comp brakes with excellent modulation and heat management
  • TranzX travel-adjustable dropper post
  • Mixed wheel setup with 29in front and 27.5in rear wheels
  • Schwalbe Magic Mary Radial Gravity tires
  • Weather-sealed internal cable routing, SRAM UDH, and Boost axle spacing
  • Three sets of bottle bosses inside the front triangle
Technical Information
  • Motor
    Bosch Gen 5 Performance Line CX, 120Nm torque
  • Battery
    800Wh
  • App
    Bosch eBike Flow App
  • Display
    Bosch Kiox 400
  • Remote
    Bosch BRC3300 Bluetooth Remote, 22.2mm clamp
  • Frame
    Series 4 Alloy, 160mm MultiTrac LT suspension, 148mm rear thru-axle
  • Front suspension
    X-Fusion Vengence, 170mm travel, 44mm offset, 110x15mm axle
  • Rear suspension
    X-Fusion H3A Air, 205x65, 30xM8 lower hardware
  • Wheelset
    Mixed (29" front, 27.5" rear), Marin double wall alloy rims, 29mm inner width, tubeless compatible
  • Hubs
    Shimano HB-MT501B rear, Shimano HF-MT500B front
  • Tires
    Schwalbe Magic Mary, Gravity Pro, Radial (Front: 29x2.5", Rear: 27.5x2.5")
  • Drivetrain
    Shimano CUES 10-speed (RD-U6000 GS derailleur, SL-U6000-10R shifter, CS-LG300-10 11-48T cassette, LG500 chain)
  • Crankset
    Marin forged eMTB, 150mm
  • Brakes
    TRP DHR EVO Comp, 200mm rotors
  • Handlebar
    Marin Mini-Riser, 6061 double butted aluminium, 780mm width, 28mm rise
  • Stem
    Marin 3D forged alloy, 35mm
  • Seatpost
    TranzX YS160QL adjustable dropper, 34.9mm (150mm travel S, 170mm travel M, 200mm travel L-XL)
  • Headset
    FSA custom, adjustable HTA design
  • Stack
    620mm (S), 634mm (M), 643mm (L), 647mm (XL)
  • Reach
    430mm (S), 460mm (M), 490mm (L), 520mm (XL)
  • Headtube angle
    63.5°
  • Seattube angle
    79°
  • Chainstay length
    442mm
  • Bottom bracket height
    352mm (352.2mm for L)
Sizing Information
GeometrySmallMediumLargeX.Large
A Stack 620634643647
B Reach 430460490520
C Headtube angle 63.5°63.5°63.5°63.5°
D Headtube length 100115125130
E Seattube length 400420430450
F Seattube angle 79°79°79°79°
G Toptube effective 556592626659
H Bb height 352352352352
I Bb drop 24 | 724 | 724 | 724 | 7
J Chainstay 442442442442
K Wheelbase 1211124812831318
L Standover height 683690695698
M Fork offset 44444444
N Seatpost diameter 34.934.934.934.9
O Handlebar width 800800800800
P Stem length 35353535
Q Crank length 160160160160
