Award winning Whyte geometry gives the mini shredder more confidence and control along with a trigger shifter to ease the transition in to adult bikes.
Award winning Whyte geometry gives the mini shredder more confidence and control along with a trigger shifter to ease the transition in to adult bikes.
Whyte Bikes

2022 Whyte 403 V2 - Burnt Orange/Khaki/Olive

£650.00
Size Guide
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

2022 Whyte 403 V2 - Burnt Orange/Khaki/Olive

Season:2021

Brand:Whyte Bikes

Code:W403V2-3

Whyte pioneered the 26’’wheeled kids bikes at the same time adult bikes moved up to larger wheel sizes.

Award winning Whyte geometry gives the mini shredder more confidence and control along with a trigger shifter to ease the transition in to adult bikes.

The 403 also comes with Whyte's own Get-a-Grip seat post clamping system. This easy to use clamp allows the post to be raised or lowered on the trail, even with small cold hands.
Technical Information
Sizes13”
Frame6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, SCR, Get A Grip Seat Clamp System, Internal Cable Routing with BBX and Chainstay Post Mount Dropouts
ForkSR Suntour XCR, 100mm Travel, Hydro Lock-out, Air Spring, Adjustable Rebound, Post Mount
HeadsetFSA No.10, Semi Integrated, 1 1/8” Caged Bearings
Rear HubAlloy, Cup & Cone, Double Seal, 28 Hole
Front HubAlloy, Cup & Cone, Double Seal, 28 Hole
Spokes2.0mm, PG, Black Stainless, Brass Nipples
RimsWhyte Trail-403, 28 Hole
TyresWTB Trail Boss Comp 26” x 2.25”
Shift LeverShimano Altus SL-M2010, Trigger Shifter, 9 Speed
Front DerailleurN/A
Rear DerailleurShimano Altus RD-M2000-SGS, 9 Speed
CassetteSunRace CSM90, ED Black 11-36, 9 Speed
ChainKMC, 9 Speed
CranksetAlloy 6061, 28T Narrow wide Chainring, Single guard, 152mm Crank Length
Bottom BracketSquare Interface, Cartridge Bearings, 73mm
SeatpostWhyte 6061 Alloy, 15mm Offset, 30.9mm x 300mm, 2 Bolt Clamp
SeatWhyte Jr Mid Custom
BarWhyte 6061 Alloy, 25mm Rise, 31.8mm, 660mm Wide
StemWhyte Alloy, 35mm Extension
GripsWhyte Lock-on V Grip
Front BrakesTektro HD-M275, Hydraulic, 160mm Disc
Rear BrakesTektro HD-M275, Hydraulic, 160mm Disc, Internal Routing
PedalsFibre Reinforced Composite Platform
Sizing Information
GEOMETRY
SIZEONE SIZE
HEAD TUBE ANGLE66.5
SEAT TUBE ANGLE76
TOP TUBE HORIZONTAL520
BB HEIGHT ABOVE GROUND295
STAND OVER HEIGHT706
WHEEL BASE1057
CHAIN STAY LENGTH410
SEAT POST DIAMETER30.9
HEAD TUBE LENGTH95
SEAT TUBE LENGTH331
STACK560
REACH380
