Frame
6061 alloy, hydroformed T6 aluminium, multi-butted, tapered head tube, internal cable routing and custom Whyte dropouts, chain stay kick stand mount
Fork
Whyte straight bladed 6061 alloy, alloy tapered steerer, internal cable routing, 12mm thru-axle, post mount with single eyelets for mudguards
Headset
No. 69 SRS, 1-1/8in upper and 1.5in lower with sealed cartridge bearings and front entry for cables
Stem
Integrated with bars
Handlebar
Whyte one piece bar and stem: 50mm extension, 720mm width, 20mm rise, seven degree backsweep, four degree upsweep
Bar Tape / Grip
Whyte Custom dual density lock-on
Brakes
Tektro T3020 Clean Sweep Design, three finger comfort lever/ Tektro T3020 hydraulic Calipers, 1.8mm thick 160mm diameter disc rotor
Tyres
Maxxis Reaver Tanwall 700 x 45c, EXO wire bead
Rear Hub/ Motor
Kynamic 250W, 36V, 45Nm 142mm power hub with replaceable freehub, 32 hole
Front Hub
Kynamic 250W, 36V, 45Nm 142mm power hub with replaceable freehub, 32 hole
Rims
WTB ST i27 rim front, WTB HTZ Trail i27 rear, 32 hole
Spokes
2.0mm, PG, black stainless, brass nipples
Front Derailleur
N/A
Rear Derailleur
Shimano Cues 9 speed, Shadow Design and direct attachment
Shift Levers
Shimano Cues 9 speed Rapidfire
Chain
Shimano Cues 9 speed
Cassette
Shimano Cues, 9 speed, 11-46T
Chainset
Shimano Cues 9 speed, 170mm, 40T chainring, with chain guard
Bottom Bracket
Kynamic BSA, square taper, 122.5mm, with torque sensor
Pedals
Fibre reinforced composite platform
Saddle
Whyte Custom
Seatpost
Whyte dropper post, 100mm drop
Weight
16.9kg (size M)
