The Ohlins TTX2 Air M.2 rear shock builds on a race-proven, robust air-sprung design, making it ideal for bikes with more progressive linkage ratios.
The TTX2 Air M.2 features twin-tube damping technology in a double-can, higher-volume air spring shock. This version has undergone internal and external overhauls to provide reduced friction, enhanced sensitivity, and improved comfort, delivering a refined, coil-like feel. Elevated ride quality is achieved through new seals and a bladder system, resulting in better rear-wheel control and improved ground contact. The updated damper allows the rear wheel to track terrain more precisely through rough sections, ensuring superior traction and handling.
An improved pedal platform provides better support during challenging climbs. The shock is compatible with remote systems that pull 7.5 mm of cable per click, including the Öhlins 3-Mode Remote, Scott TwinLoc, and Orbea Squidlock. A redesigned spacer system makes it easier to adjust the air volume in the positive chamber, and stroke adjustment has been simplified. Externally, the shock includes a redesigned adjustment knob for intuitive tuning on the fly.
Features:
- Highly adjustable TTX compression valve technology
- Double-can design with larger air volume in both positive and negative chambers
- Adjustable HSC (high-speed compression) and LSC (low-speed compression)
- Adjustable rebound damping
- Climb mode
- Race-proven setting bank
- Air spring volume spacers included
- Compatible with remote systems
- Maximum air pressure: 325 psi
