You’ll find it hard to believe the 603 is Whyte’s entry level mountain bike
You’ll find it hard to believe the 603 is Whyte’s entry level mountain bike
Whyte

2022 Whyte 603 V3 Hardtail Mountain Bike- Gloss Cement/ Burnt Orange/ Slate

Size Guide
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

2022 Whyte 603 V3 Hardtail Mountain Bike- Gloss Cement/ Burnt Orange/ Slate

Season:2022

Brand:Whyte

Code:W603

Whyte’s design team have given the latest 600 series frame the Trail treatment.

A 120mm fork, wider 740mm bar,shorter stem, wider grippier tyres and even our Enduro developed V-grips, make these the most trail-ready bikes inthis price category.

You’ll find it hard to believe the 603 is Whyte’s entry level mountain bike: with carefully chosen, branded parts and ahigh quality, latest generation frame it has all the hallmarks of Whyte’s award winning DNA.The latest frame has been upgraded to give a full trail experience
Technical Information
Frame6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Internal Cable Routing with BBX, Chainstay Post Mount Dropouts
ForkSR Suntour XCR-LO 27.5", 120mm Travel, Tapered Steerer, Hydro Lockout, Fixed Rebound Damping, Black Stanchions
HeadsetFEIMIN H807B, Semi Integrated, 1 1/8" Lower 1 1/2 Lower Caged Bearings
Rear HubAlloy, Cup & Cone, Double Seal, 32 Hole
Front HubAlloy, Cup & Cone, Double Seal, 32 Hole
Spokes2.0mm, PG, Black Stainless, Brass Nipples
RimsWhyte Trail 25, Tubeless compatible, 32 Hole
TyresMAXXIS Forekaster 27.5" x 2.35" Front, MAXXIS Recon Race 27.5" x 2.25" Rear Wire Bead
Shift LeversShimano Altus SL-M2010, 9 Speed
Front DerailleurShimano Altus FD-M2020
Rear DerailleurShimano Altus RD-M2000-SGS, 9 Speed
CassetteShimano CS-HG-200, 11-36, 9 Speed
ChainSunRace, 9 Speed
CranksetShimano FC-MT101, Double 36-22, 9 Speed
Bottom BracketSquare Interface, Cartridge Bearings, 73mm
SeatpostWhyte 6061 Alloy, 12mm Offset, 30.9mm x S/M 350mm, L/XL 400mm, 2 Bolt Clamp
SeatWhyte Custom
BarWhyte 6061 Alloy, 30mm Rise, 31.8mm, 760mm Wide
StemWhyte Alloy, S 35mm, M/L/XL 45mm
GripsWhyte Lock-on V Grip
Front BrakeTektro HD-M275, Hydraulic, 180mm Rotor
Rear BrakeTektro HD-M275, Hydraulic, 160mm Rotor, Internal Routing
Brake LeversTektro HD-M275
PedalsFibre Reinforced Composite Platform - Click here to choose an upgrade pedal
Sizing Information
GEOMETRY
SIZESMLXL
HEAD TUBE ANGLE66.566.566.566.5
SEAT TUBE ANGLE74747474
TOP TUBE HORIZONTAL604623641660
BB HEIGHT ABOVE GROUND303.5303.5303.5303.5
STAND OVER HEIGHT780802826864
WHEEL BASE1148116811881208
CHAIN STAY LENGTH435435435435
SEAT POST DIAMETER30.930.930.930.9
HEAD TUBE LENGTH115125135145
SEAT TUBE LENGTH406444482.6533
STACK609619628637
REACH430445461477
