| SPECIFICATION |
|---|
| COLOUR | Matt Black Burnt Orange/Grey | CASSETTE | SRAM XG-1275 Eagle, 10-52, 12 Speed |
| FRAME | 6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing, Shape.it Link and 12mm X 148mm Boost Dropouts | CHAIN | SRAM GX Eagle, 12 Speed |
| FORK | Fox Float 38, Factory 27.5", 180mm Travel, 44mm Offset with Grip 2 Damper and custom tune, Tapered Steerer, Kashima Coating, 110mm x 15mm Boost, E-Thru Axle | CRANKSET | Race Face Affect E-Bike, 165mm, ISIS with X-SYNC Direct Mount 36T for Bosch Performance Line CX, Black |
| REAR SHOCK | Fox Float X2, Factory, independently adjustable Compression and Rebound damping, Kashima coating | BOTTOM BRACKET | N/A |
| HEADSET | FSA No. 57E Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings | SEATPOST | Crank Bro High-Line 3, 30.9mm, M/L 150mm Travel, XL 170mm Travel, High-Line Ball Socket Remote Lever |
| REAR HUB | DT Swiss 350 Straightpull with 24T Ratchet System, 12mm x 148mm, 6 Bolt with Magnet carrier, 28 Hole | SADDLE | Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail |
| FRONT HUB | DT Swiss 350, 15mm x 110mm, Centre-Lock, 28 Hole | HANDLEBAR | Race Face Turbine R, 35mm Rise, 35mm Bar Bore, 800mm Wide |
| SPOKES | DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples | STEM | Race Face Atlas, 35mm Bar Bore, 35mm Extension |
| RIMS | DT Swiss Hybrid 30, Sleeved Joint, 28 Hole | GRIPS | Whyte Lock-on Enduro Grip |
| TYRE | Maxxis Assigai WT, TR, 27.5" x 2.5" 120TPI, EXO + Sidewall Protection, 3C Maxx Terra, Dual Compound, Folding Bead, Front, Maxxis Assigai WT, TR, 27.5" x 2.5" 120TPI, Double Down Casing, 3C Maxx Terra, Dual Compound, Rear | BRAKES FRONT | SRAM Code RSC, 4 Piston with Sintered Metal Pads, 220mm Disc |
| SHIFT LEVERS | SRAM X01-E Eagle, Single Click, MMX, 12 Speed | BRAKES REAR | SRAM Code RSC, 4 Piston with Sintered Metal Pads, 200mm Disc |
| FRONT MECH | N/A | BRAKE LEVERS | SRAM Code RSC, MMX |
| REAR MECH | SRAM X01 Eagle, 12 Speed | PEDALS | Click here to choose some suitable new pedals |
| WEIGHT | TBC | | |
